Square D EGB36025 Circuit Breaker | EGB Series EGB 480V 25A

Product Description:
The Square D EGB36025 is a Molded Case Circuit Breaker from the EGB Series. It features a 3-pole design with a 480V, 25A rating and a 35kA@480V AIC rating. This breaker uses a Bolt-On connection and includes Thermal Magnetic protection for reliable performance.

Key Features:
✔ Part Number: EGB36025
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: EGB Series
✔ Type: EGB
✔ Voltage: 480V
✔ Amperage: 25A
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 35kA@480V
✔ Connection: Bolt-On
✔ Protection: Thermal Magnetic
✔ Certification: cULus
✔ UPC: 785901239154
✔ GTIN: 00785901239154
✔ Country of Origin: Mexico
✔ Dimensions: 5.66" H x 3.09" D x 4.44" W
✔ Weight: 1.65 lbs
✔ Panel Type: NF panelboard
✔ Wire Size: AWG 12...AWG 6 aluminum, AWG 14...AWG 6 copper
