Square D EJB36050 Circuit Breaker | 600V 50A

Product Description:
The Square D EJB36050 is a 3-pole molded case circuit breaker with a 600V, 50A rating and a 65kA@480V AIC rating. It features thermal magnetic protection and a bolt-on connection. Suitable for NF panelboards, it supports wire sizes from AWG 12 to AWG 2/0 aluminum and AWG 14 to AWG 2/0 copper.

Key Features:
✔ Part Number: EJB36050
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Voltage: 600V
✔ Amperage: 50A
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 65kA@480V
✔ Connection: Bolt-On
✔ Protection: Thermal Magnetic
✔ Panel Type: NF panelboard
✔ Certification: cULus
✔ Wire Size: AWG 12...AWG 2/0 aluminum
AWG 14...AWG 2/0 copper
✔ UPC: 785901407133
✔ GTIN: 00785901407133
✔ Country of Origin: United States
✔ Dimensions: 5.66 x 3.09 x 4.44 in (143.76 x 78.49 x 112.78 mm)
✔ Weight: 1.57 lbs
