Eaton FAZ-D13/1-NA-SP Circuit Breaker | 36V 13A 1P 10kA@480/277V Feed-Thru FAZ Series

Product Description:
The Eaton FAZ-D13/1-NA-SP is a Molded Case Circuit Breaker from the FAZ Series. It features 1 pole, 36 Volt, and 13 amp ratings with a 10kA@480/277V AIC rating. This breaker uses Feed-Thru connections and offers Thermal Magnetic protection. It is CSA Certified and UL 489 Listed for safety compliance.

Key Features:
✔ Part Number: FAZ-D13/1-NA-SP
✔ Manufacturer: Eaton, Cutler Hammer
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: FAZ Series
✔ Type: FAZ
✔ Voltage: 36
✔ Amperage: 13
✔ Phase: 1
✔ Poles: 1
✔ AIC rating: 10kA@480/277V
✔ Connection: Feed-Thru
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Screw Clamp
✔ Frame Size: 40A/FAZ
✔ MCM Size: Min. Wire Size 18 AWG Max. Wire Size 6 AWG
✔ Protection: Thermal Magnetic
✔ UPC: 78668900522
✔ GTIN: 00786689005221
✔ Country of Origin: Spain
✔ Weight: 0.25
✔ Standards: CSA Certified, IEC 60947-2, UL 489 Listed
