Product Description:
The Cutler Hammer FD1125L is a Molded Case Circuit Breaker from the Series C family. It features a 1-pole design with a 277V, 125A rating and a 35kA@277V AIC rating. This breaker uses Feed-Thru connections and includes Thermal Magnetic protection. It is UL Listed and compliant with UL 489 standards.
Key Features:
✔ Part Number: FD1125L
✔ Manufacturer: Cutler Hammer, Eaton, Westinghouse
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Series C
✔ Type: FD
✔ Voltage: 277V
✔ Amperage: 125A
✔ Phase: 1
✔ Poles: 1
✔ AIC Rating: 35kA@277V
✔ Connection: Feed-Thru
✔ Protection: Thermal Magnetic
✔ Frame Size: F Frame
✔ Certification: UL Listed, UL 489
✔ UPC: 786679026656
✔ GTIN: 00786679026656
✔ Country of Origin: Dominican Republic
✔ Dimensions: 3.38in (L) x 1.38in (H) x 1.38in (W)
✔ Weight: 4.5 lbs
