GHB3015 Cutler-Hammer 15 Amp 3-Pole Bolt-On Circuit Breaker Eaton G-Frame 480V

GHB3015 Cutler-Hammer 15 Amp 3-Pole Bolt-On Circuit Breaker Eaton G-Frame 480V

Need a direct replacement G-frame branch breaker for your Eaton panelboard? This Cutler-Hammer GHB3015 drops in and handles your 15-amp three-phase loads seamlessly. Built for daily jobsite durability, this heavy-duty bolt-on breaker attaches securely onto the panel bus to prevent loose connections, delivering reliable overcurrent and short-circuit protection right where you need it.

The GHB3015 features standard factory-installed load lugs that accept 14 to 10 AWG copper or aluminum wiring, making field installations fast and straightforward. It operates on 50/60 Hz commercial distribution systems up to 480Y/277VAC, as well as 125/250VDC systems. With a solid 14 kAIC interrupting rating at 480V, you can swap this unit into your industrial or commercial panelboards with total trade confidence.

Common Applications

• Direct branch replacements in commercial Eaton powerline panelboards.
• Field maintenance swap-outs for commercial HVAC and cooling machinery.
• Three-phase motor branch circuits and specialized industrial control panels.

Key Features

• Contractor-Ready Fit: Standard G-frame footprint drops directly into commercial style bolt-on panelboards without extra modification.
• Rugged Lugs: Built-in industrial load terminals support clean, torqued field terminations for both aluminum and copper feeds.
• Fixed Protection: Sealed thermal-magnetic internal trip mechanisms prevent jobsite tampering and deliver reliable long-term safety.
• Simultaneous Trip: Engineered with internal common-trip linkages to drop all three poles instantly during a fault event.

Specifications

• Amperage Rating: 15A
• Voltage Rating: 480Y/277VAC, 125/250VDC
• Number of Poles: 3-Pole
• Interrupt Rating: 14 kAIC at 480Y/277VAC, 65 kAIC at 240VAC
• Frame Size: G-Frame
• Trip Type: Non-Interchangeable Thermal-Magnetic
• Terminal Connection: Standard Load Lugs Included
• Wire Range: 14 to 10 AWG (Cu/Al)
• Frequency: 50/60 Hz
• Certifications: UL Listed, CSA Certified

Product Identification

• Country of Origin: United States
• Dimensions: 4.0 in H x 3.0 in W x 2.63 in D
• Weight: 1.75 lb
• UPC/GTIN: 786679911259

FAQ

Q: Does this breaker come with the line-side bolt-on hardware?
A: Yes, the integrated bolt-on line tab mounting configuration is standard for direct attachment to panelboard bus bars.

Q: Can I use this GHB3015 breaker on a standard single-phase system?
A: This is a 3-pole unit designed for three-phase systems, though it can be applied in specific multi-wire configurations according to code.

Q: Is this a thermal-magnetic breaker or electronic?
A: The GHB3015 is a traditional thermal-magnetic breaker equipped with fixed magnetic and fixed thermal tripping thresholds.

Q: What is the torque requirement for the load terminals?
A: Always refer to the faceplate label on the breaker frame for exact manufacturer-specified wire terminal torque values.
