Siemens HED41B025 Circuit Breaker | 277V 25A 1P 65kA@277V Sentron Series

Product Description:
The Siemens HED41B025 is a Molded Case Circuit Breaker from the Sentron Series family. It features a 1-pole design with a 277V, 25A rating and a 65kA@277V AIC rating. This breaker uses a Lug In Panelboard connection and offers Thermal Magnetic protection for reliable performance.

Key Features:
✔ Part Number: HED41B025
✔ Manufacturer: Siemens
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Sentron Series
✔ Type: HED
✔ Voltage: 277
✔ Amperage: 25
✔ Phase: 1
✔ Poles: 1
✔ AIC rating: 65kA@277V
✔ Connection: Lug In Panelboard
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Load Side Lug
✔ Frame Size: 125A/ED
✔ MCM Size: Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 10 AWG
✔ Breaker Type: Standard
✔ Protection: Thermal Magnetic
✔ Phase Connection: ABC
✔ UPC: 783643209831
✔ GTIN: 00783643209831
✔ Country of Origin: Mexico
✔ Dimensions: 1 in x 6.34 in
✔ Weight: 3
✔ Panel Type: SB Switchboards, Sentron Panelboards
✔ Standards: HACR Rated, UL Listed
✔ Certification: HACR Rated, UL Listed
