Product Description:
The Square D HJL26100 is a Powerpact family molded case circuit breaker designed for reliable circuit protection. It is a 2-pole, 100 amp breaker rated for 600 volts with a 65kA interrupting capacity at 480V. This thermal magnetic breaker features a feed-thru lug connection and supports a wide range of wire sizes from 14 AWG to 3/0 AWG.
Key Features:
✔ Part Number: HJL26100
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: HJL
✔ Voltage: 600
✔ Amperage: 100
✔ Poles: 2
✔ AIC Rating: 65kA@480V
✔ Connection: Feed-Thru
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: H
✔ Wire Size: Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
✔ Protection: Thermal Magnetic
✔ UPC: 785901706656
✔ GTIN: 00785901706656
✔ Country of Origin: Mexico
✔ Dimensions: 2.74 in x 6.4 in
✔ Weight: 1.8
✔ Standards: UL, CSA, NEMA, NOM, CE
✔ Certification: UL, CSA, NEMA, NOM, CE
The Square D HJL26100 is a Powerpact family molded case circuit breaker designed for reliable circuit protection. It is a 2-pole, 100 amp breaker rated for 600 volts with a 65kA interrupting capacity at 480V. This thermal magnetic breaker features a feed-thru lug connection and supports a wide range of wire sizes from 14 AWG to 3/0 AWG.
