Square D HJL36100M73 Circuit Breaker | 690VAC 100A 3P 65kA@480V Feed-Thru Powerpact

Product Description:
The Square D HJL36100M73 is a Molded Case Circuit Breaker from the Powerpact family. It is a 3-pole breaker rated for 100 amps and 690 AC volts, with an AIC rating of 65kA at 480V. This model features a feed-thru connection and magnetic-only protection for reliable circuit interruption.

Key Features:
✔ Part Number: HJL36100M73
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: HJL
✔ Voltage: 690 AC
✔ Amperage: 100
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 65kA@480V
✔ Connection: Feed-Thru
✔ Functions: I - Instantaneous
✔ Frame Size: H Frame
✔ Protection: Magnetic Only
✔ UPC: 785901647706
✔ GTIN: 00785901647706
✔ Country of Origin: Mexico
✔ Dimensions: 104 mm x 163 mm
✔ Weight: 4
✔ Certification: UL, CSA, NOM-003-SCFI-2000, IEC 60947-2, IEC 60947-1, CE
✔ Wire Size: AWG 14...AWG 3/0 aluminum/copper terminal
