Square D HOM245GFI Circuit Breaker | 240V 45A 2P 10kA@240V HOMELINE

Product Description:
The Square D HOM245GFI is a Molded Case Circuit Breaker from the HOMELINE family. It features a 2-pole design with a 240V, 45A rating and a 10kA@240V AIC rating. This breaker uses a plug-in connection and offers thermal magnetic protection. It is UL Listed and designed for reliable performance in electrical panels.

Key Features:
✔ Part Number: HOM245GFI
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: HOMELINE
✔ Type: HOM
✔ Voltage: 240
✔ Amperage: 45
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 10kA@240V
✔ Connection: Plug-In
✔ Functions: LI - Long-Time and Instantaneous
✔ Breaker Type: Ground fault protecting class A 6 mA
✔ Protection: Thermal Magnetic
✔ UPC: 785901508243
✔ GTIN: 00785901508243
✔ Country of Origin: Mexico
✔ Dimensions: 4.23 in(H) X 2 in (W) X 2.98 in (D)
✔ Weight: 0.55 lb
✔ Panel Type: Homine
✔ Certification: UL Listed
✔ Wire Size: 40.71 lbf.in (4.6 N.m) 0.00...0.02 in² (2.5...10 mm²) (AWG 16...AWG 14)
