Square D QBL22150 Circuit Breaker | Powerpact QBL 240V 150A
Square D QBL22150 Circuit Breaker | Powerpact QBL 240V 150A
Price:
Sale
Sold out
Regular price
$243.81 USD
Regular price
$474.00 USD
Sale price
$243.81 USD
Unit price
per
Shipping calculated at checkout.
Stock:
100+ in stock
Couldn't load pickup availability
Product Description:
The Square D QBL22150 is a Molded Case Circuit Breaker from the Powerpact family. It is a 2-pole, 240V, 150A breaker with a 10kA@240V AIC rating and Bolt-On connection. This thermal magnetic breaker is designed for standard applications with a frame size of 250A/QB.
Key Features:
✔ Part Number: QBL22150
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: QBL
✔ Voltage: 240V
✔ Amperage: 150A
✔ Phase: 1
✔ Poles: 2
✔ AIC Rating: 10kA@240V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Line/Load Lug
✔ Frame Size: 250A/QB
✔ MCM Size: Min. Wire Size 4 AWG, Max. Wire Size 300 MCM
✔ Breaker Type: Standard
✔ Temp Rating: 104-158°F (40-70°C)
✔ Certification: CSA, IEC, UL Listed
✔ UPC: 785
The Square D QBL22150 is a Molded Case Circuit Breaker from the Powerpact family. It is a 2-pole, 240V, 150A breaker with a 10kA@240V AIC rating and Bolt-On connection. This thermal magnetic breaker is designed for standard applications with a frame size of 250A/QB.
Key Features:
✔ Part Number: QBL22150
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: QBL
✔ Voltage: 240V
✔ Amperage: 150A
✔ Phase: 1
✔ Poles: 2
✔ AIC Rating: 10kA@240V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Line/Load Lug
✔ Frame Size: 250A/QB
✔ MCM Size: Min. Wire Size 4 AWG, Max. Wire Size 300 MCM
✔ Breaker Type: Standard
✔ Temp Rating: 104-158°F (40-70°C)
✔ Certification: CSA, IEC, UL Listed
✔ UPC: 785
