Square D QBL32200 Circuit Breaker | Powerpact QBL 240V 200A
Square D QBL32200 Circuit Breaker | Powerpact QBL 240V 200A
Price:
Sale
Sold out
Regular price
$536.44 USD
Regular price
$1,248.00 USD
Sale price
$536.44 USD
Unit price
per
Shipping calculated at checkout.
Stock:
100+ in stock
Couldn't load pickup availability
Product Description:
The Square D QBL32200 is a Molded Case Circuit Breaker from the Powerpact family. It is a 3-pole, 240V, 200A breaker with a 10kA@240V AIC rating and Bolt-On connection. It features Thermal Magnetic protection and is designed for standard applications.
Key Features:
✔ Part Number: QBL32200
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: QBL
✔ Voltage: 240V
✔ Amperage: 200A
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 10kA@240V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Line/Load Lug
✔ Frame Size: 250A/QB
✔ MCM Size: Min. Wire Size 4 AWG, Max. Wire Size 300 MCM
✔ Breaker Type: Standard
✔ Temp Rating: 104-158 °F (40-70 °C)
✔ Certification: CSA, IEC, UL Listed
✔ UPC: 785901417866
✔ GTIN
The Square D QBL32200 is a Molded Case Circuit Breaker from the Powerpact family. It is a 3-pole, 240V, 200A breaker with a 10kA@240V AIC rating and Bolt-On connection. It features Thermal Magnetic protection and is designed for standard applications.
Key Features:
✔ Part Number: QBL32200
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: QBL
✔ Voltage: 240V
✔ Amperage: 200A
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 10kA@240V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Line/Load Lug
✔ Frame Size: 250A/QB
✔ MCM Size: Min. Wire Size 4 AWG, Max. Wire Size 300 MCM
✔ Breaker Type: Standard
✔ Temp Rating: 104-158 °F (40-70 °C)
✔ Certification: CSA, IEC, UL Listed
✔ UPC: 785901417866
✔ GTIN
