Square D QBL32225 Circuit Breaker | 240V 225A 3P 10kA@240V Bolt-On Powerpact

Product Description:
The Square D QBL32225 is a Molded Case Circuit Breaker from the Powerpact family. It is a 3-pole, 225 amp breaker rated for 240 volts with a 10kA interrupting capacity. This model features thermal magnetic protection and a bolt-on connection for secure installation.

Key Features:
✔ Part Number: QBL32225
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: QBL
✔ Voltage: 240
✔ Amperage: 225
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 10kA@240V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Line/Load Lug
✔ Frame Size: 250A/QB
✔ MCM Size: Min. Wire Size 4 AWG Max. Wire Size 300 MCM
✔ Breaker Type: Standard
✔ Protection: Thermal Magnetic
✔ Phase Connection: ABC
✔ UPC: 785901417880
✔ GTIN: 00785901417880
✔ Country of Origin: Mexico
✔ Dimensions: 4.5 in x 6.47 in
✔ Weight: 2.15
✔ Standards: CSA, IEC, UL Listed
✔ Certification: CSA, IEC, UL Listed
