Square D QOU1100 Circuit Breaker | 120/240V 100A 1P Unit Mount QOU Series

Product Description:
The Square D QOU1100 is a Molded Case Circuit Breaker from the QOU Series family. It is a 1-pole, 100 amp rated breaker designed for 120/240 Volt applications. This unit features Thermal Magnetic protection and uses a Unit Mount connection for secure installation. It is suitable for use in air conditioning, refrigeration, and heating panels.

Key Features:
✔ Part Number: QOU1100
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: QOU Series
✔ Type: QOU
✔ Voltage: 120/240
✔ Amperage: 100
✔ Phase: 1
✔ Poles: 1
✔ Connection: Unit Mount
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Slotted Box Lug (Non-Reversible Line and Load)
✔ Frame Size: 100A/QOU
✔ MCM Size: Min. Wire Size 12 AWG Max. Wire Size 2/0 AWG
✔ Breaker Type: Standard
✔ Protection: Thermal Magnetic
✔ UPC: 785901478546
✔ GTIN: 00785901478546
✔ Country of Origin: Mexico
✔ Dimensions: 0.75 in x 4.05 in x 4.45 in
✔ Weight: 0.48
✔ Panel Type: Air Conditioning and Refrigeration Equipment, Heating
✔ Standards: CSA, IEC, UL listed
✔ Certification: IEC, UL listed
✔ Wire Size: AWG 12...AWG 2/0 aluminum/copper
