Square D QOU2125 Circuit Breaker | 240V 125A 2P 10kA@240V QOU Series

Product Description:
The Square D QOU2125 is a 2-pole molded case circuit breaker with a 125 amp rating and 240V capacity. It features thermal magnetic protection and a bolt-on connection for secure installation. This breaker has an AIC rating of 10kA@240V and is part of the QOU Series family. It is suitable for air conditioning, refrigeration, and heating applications.

Key Features:
✔ Part Number: QOU2125
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: QOU Series
✔ Type: QOU
✔ Voltage: 240
✔ Amperage: 125
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 10kA@240V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Slotted Box Lug (Non-Reversible Line and Load)
✔ Frame Size: 100A/QOU
✔ MCM Size: Min. Wire Size 12 AWG Max. Wire Size 2/0 AWG
✔ Breaker Type: Standard
✔ Protection: Thermal Magnetic
✔ UPC: 785901060765
✔ GTIN: 00785901060765
✔ Country of Origin: Mexico
✔ Dimensions: 1.5 in x 4.45 in
✔ Weight: 0.95
✔ Panel Type: Air Conditioning and Refrigeration Equipment, Heating
✔ Standards: CSA, IEC, UL listed
✔ Certification: IEC, UL listed
✔ Wire Size: AWG 12...AWG 2/0 aluminum/copper
