Square D QOU2801042 Circuit Breaker | 240V 80A 2P 10kA@240V Bolt-On QOU Series
Square D QOU2801042 Circuit Breaker | 240V 80A 2P 10kA@240V Bolt-On QOU Series
Price:
Sale
Sold out
Regular price
$636.86 USD
Regular price
$435.00 USD
Sale price
$636.86 USD
Unit price
per
Shipping calculated at checkout.
Stock:
Out of stock
Couldn't load pickup availability
Product Description:
The Square D QOU2801042 is a Molded Case Circuit Breaker from the QOU Series. It features a 2-pole design with a 240V, 80A rating and a 10kA@240V AIC rating. This circuit breaker uses a Bolt-On connection and offers Thermal Magnetic protection for reliable performance.
Key Features:
✔ Part Number: QOU2801042
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: QOU Series
✔ Type: QOU
✔ Voltage: 240
✔ Amperage: 80
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 10kA@240V
✔ Connection: Bolt-On
✔ Protection: Thermal Magnetic
✔ GTIN: 00785901559948
✔ Dimensions: Height 4.45 in (113.03 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
✔ Certification: UL listed - IEC - CSA
✔ Wire Size: AWG 12...AWG 2/0 aluminum/copper
The Square D QOU2801042 is a Molded Case Circuit Breaker from the QOU Series. It features a 2-pole design with a 240V, 80A rating and a 10kA@240V AIC rating. This circuit breaker uses a Bolt-On connection and offers Thermal Magnetic protection for reliable performance.
Key Features:
✔ Part Number: QOU2801042
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: QOU Series
✔ Type: QOU
✔ Voltage: 240
✔ Amperage: 80
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 10kA@240V
✔ Connection: Bolt-On
✔ Protection: Thermal Magnetic
✔ GTIN: 00785901559948
✔ Dimensions: Height 4.45 in (113.03 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
✔ Certification: UL listed - IEC - CSA
✔ Wire Size: AWG 12...AWG 2/0 aluminum/copper
