Product Description:
The Cutler Hammer XTCE065D00B is a 600V 3-phase 65A 3-pole contactor for motor control applications. It features a 240V coil and is rated for 20 hp at 208V, 25 hp at 240V, and 50 hp at 480V. This non-reversing contactor is designed for industrial use with high durability and compliance with multiple certifications.
Key Features:
✔ Part Number: XTCE065D00B
✔ Manufacturer: Cutler Hammer
✔ Category: Motor Control
✔ Subcategory: Contactor
✔ Family: XT Series
✔ Type: XTCE065D
✔ Voltage: 600
✔ Amperage: 65
✔ Phase: 3
✔ Poles: 3
✔ Horse Power: HP @ 3 Phase - 208V 20 hp HP @ 3 Phase - 240V 25 hp HP @ 3 Phase - 480V 50 hp
✔ Configuration: Non-Reversing
✔ Aux Contacts: 0 NO + 0 NC
✔ Coil Voltage Maximum: 240
✔ Full Load Amps: Full Load Amps-Inductive 65A Full Load Amps-Resistive 98A
✔ Coil Voltage Minimum: 240
✔ Frequency: 50 Hz
✔ UPC: 786685363271
✔ GTIN: 04015082778934
✔ Country of Origin: Romania
✔ Dimensions: 2.17 in x 2.17 in
✔ Weight: 1 lb
✔ Certification: CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed
