Siemens BE260H Circuit Breaker | BL Series BLEH 240V 60A

Product Description:
The Siemens BE260H is a Molded Case Circuit Breaker from the BL Series. It features a 2-pole design with a 240V, 60A rating and a 22kA@240V AIC rating. This BLEH-type breaker uses a Bolt-On connection and includes Thermal Magnetic protection. It is compatible with Siemens P1 Panelboards and meets CSA, HACR, NOM, and UL standards.

Key Features:
✔ Part Number: BE260H
✔ Manufacturer: Siemens
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: BL Series
✔ Type: BLEH
✔ Voltage: 240V
✔ Amperage: 60A
✔ Phase: 1
✔ Poles: 2
✔ AIC Rating: 22kA@240V
✔ Connection: Bolt-On
✔ Protection: Thermal Magnetic
✔ Terminal Connection: Lug
✔ Frame Size: 60A/BLEH
✔ Min. Wire Size: 12 AWG (Al), 14 AWG (Cu)
✔ Max. Wire Size: 6 AWG
✔ Panel Type: Siemens P1 Panelboards
✔ Certification: CSA Certified, HACR Rated, NOM Certified, UL Listed
✔ UPC: 783643274211
✔ GTIN: 00783643274211
✔ Country of Origin: Philippines
✔ Dimensions: 2.756 x 1.969 x 5.906
✔ Weight: 1.04 lbs
