Square D EDB14025SA Circuit Breaker | 277V 25A 1P 18kA@480V Bolt-On EDB Series

Product Description:
The Square D EDB14025SA is a Molded Case Circuit Breaker from the EDB Series. It features a 1 pole, 277 Volt, 25 amp rating with an AIC rating of 18kA@480V. This circuit breaker uses a Bolt-On connection and includes Thermal Magnetic protection. It is complete with a 120V shunt trip for added functionality.

Key Features:
✔ Part Number: EDB14025SA
✔ Manufacturer: Square D||Schneider Electric
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: EDB Series
✔ Type: EDB
✔ Voltage: 277
✔ Amperage: 25
✔ Phase: 1
✔ Poles: 1
✔ AIC rating: 18kA@480V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Protection: Thermal Magnetic
✔ GTIN: 00785901641216
✔ Dimensions: Height 5.66 in (143.76 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
✔ Panel Type: NF panelboard
✔ Certification: IEC - cULus
✔ Wire Size: AWG 12...AWG 6 aluminum / AWG 14...AWG 6 copper
