Square D EDB14030EPD Circuit Breaker | 277V 30A 1P 18kA@480V Bolt-on EDB Series

Product Description:
The Square D EDB14030EPD is a Molded Case Circuit Breaker from the EDB Series. It features a 1-pole design with a 277V, 30A rating and an 18kA@480V AIC rating. This breaker uses a bolt-on connection and offers thermal magnetic protection. It is suitable for NF panelboards and complies with cULus and IEC standards.

Key Features:
✔ Part Number: EDB14030EPD
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: EDB Series
✔ Type: EDB
✔ Voltage: 277
✔ Amperage: 30
✔ Phase: 1
✔ Poles: 1
✔ AIC rating: 18kA@480V
✔ Connection: Bolt-on
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: 125A/EDB
✔ MCM Size: Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 4 AWG (Al), 6 AWG (Cu)
✔ Breaker Type: Ground Fault Equipment Protection
✔ Protection: Thermal Magnetic
✔ UPC: 785901475576
✔ GTIN: 00785901475576
✔ Country of Origin: Mexico
✔ Dimensions: 1.96 in x 6.64 in x 6.64 in
✔ Weight: 1
✔ Panel Type: NF panelboard
✔ Standards: cULus, IEC
✔ Certification: cULus, IEC
✔ Wire Size: AWG 14...AWG 6 copper, AWG 12...AWG 4 aluminum
