Square D EDB14030SA Circuit Breaker | 277V 30A 1P 18kA@480V Bolt-On EDB Series

Product Description:
The Square D EDB14030SA is a Molded Case Circuit Breaker from the EDB Series. It features a 1-pole design with a 277V voltage rating and 30A amperage capacity. This breaker includes thermal magnetic protection and a bolt-on connection for secure installation. It has an AIC rating of 18kA@480V and comes with a 120V shunt trip.
Key Features:
✔ Part Number: EDB14030SA
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: EDB Series
✔ Type: EDB
✔ Voltage: 277
✔ Amperage: 30
✔ Phase: 1
✔ Poles: 1
✔ AIC rating: 18kA@480V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Protection: Thermal Magnetic
✔ UPC: 785901453314
✔ GTIN: 00785901453314
✔ Country of Origin: Ireland
✔ Dimensions: Height 5.66 in (143.76 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
✔ Panel Type: NF panelboard
✔ Certification: cULus - IEC
✔ Wire Size: AWG 12...AWG 6 aluminum / AWG 14...AWG 6 copper
