Square D EGB24090 Molded Case Circuit Breaker | 480V 90A 2P 35kA@480V Bolt-On EGB Series

Product Description:
The Square D EGB24090 is a 2-pole molded case circuit breaker designed for 480V applications. It provides reliable circuit protection with a 90A current rating and a 35kA interrupting capacity. This thermal magnetic breaker features bolt-on connections for secure installation in compatible panelboards.

Key Features:
✔ Part Number: EGB24090
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: EGB Series
✔ Type: EGB
✔ Voltage: 480
✔ Amperage: 90
✔ Poles: 2
✔ AIC rating: 35kA@480V
✔ Connection: Bolt-On
✔ Protection: Thermal Magnetic
✔ UPC: 785901325000
✔ GTIN: 00785901325000
✔ Country of Origin: United States
✔ Dimensions: Height 5.66 in (143.76 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
✔ Weight: 1.12
✔ Panel Type: NF panelboard
✔ Certification: cULus
✔ Wire Size: AWG 12...AWG 2/0 aluminum, AWG 14...AWG 2/0 copper
