Square D EGB24110 Circuit Breaker | EGB Series EGB 480V 110A

Product Description:
The Square D EGB24110 is a Molded Case Circuit Breaker from the EGB Series. It features 2 poles, 480V voltage, and a 110A amperage rating with a 35kA@480V AIC rating. This breaker uses a Bolt-On connection and includes Thermal Magnetic protection for reliable performance.

Key Features:
✔ Part Number: EGB24110
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: EGB Series
✔ Type: EGB
✔ Voltage: 480V
✔ Amperage: 110A
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 35kA@480V
✔ Connection: Bolt-On
✔ Protection: Thermal Magnetic
✔ UPC: 785901128601
✔ GTIN: 00785901000000
✔ Country of Origin: Mexico
✔ Dimensions: 5.66 in x 3.09 in x 4.44 in (143.76 mm x 78.49 mm x 112.78 mm)
✔ Weight: 1.12 lbs
✔ Panel Type: NF panelboard
✔ Certification: cULus
✔ Wire Size: AWG 12...AWG 2/0 aluminum, AWG 14...AWG 2/0 copper
