Westinghouse GHB3090S1 Circuit Breaker | Series C GHB 480V 90A

Product Description:
The Cutler Hammer GHB3090S1 is a Molded Case Circuit Breaker from the Series C family. It features a 3-pole design with a 480V, 90A rating and a 14kA@480V AIC rating. This breaker uses a Bolt-On connection and includes Thermal Magnetic protection. Manufactured by Westinghouse, it is UL Listed and meets Federal Specifications.

Key Features:
✔ Part Number: GHB3090S1
✔ Manufacturer: Westinghouse
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Series C
✔ Type: GHB
✔ Voltage: 480V
✔ Amperage: 90A
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 14kA@480V
✔ Connection: Bolt-On
✔ Protection: Thermal Magnetic
✔ Frame Size: G Frame
✔ Certification: UL Listed, Federal Specifications Classification W-C375B
✔ Wire Size: 10 to 1/0 AWG
✔ UPC: 786679020883
✔ GTIN: 00786679020883
✔ Country of Origin: Dominican Republic
✔ Dimensions: 2.63in (L) x
