Siemens HED41B100 Circuit Breaker | 277V 100A 1P 25kA@277V Sentron Series

Product Description:
The Siemens HED41B100 is a Molded Case Circuit Breaker from the Sentron Series family. It features a 1-pole design with a 277V, 100A rating and a 25kA@277V AIC rating. This breaker uses a Lug In Panelboard connection and offers Thermal Magnetic protection for reliable performance.

Key Features:
✔ Part Number: HED41B100
✔ Manufacturer: Siemens
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Sentron Series
✔ Type: HED
✔ Voltage: 277
✔ Amperage: 100
✔ Phase: 1
✔ Poles: 1
✔ AIC rating: 25kA@277V
✔ Connection: Lug In Panelboard
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Load Side Lug
✔ Frame Size: 125A/ED
✔ MCM Size: Min. Wire Size 10 AWG Max. Wire Size 4 AWG
✔ Breaker Type: High Interrupting Capacity
✔ Protection: Thermal Magnetic
✔ Phase Connection: Any
✔ UPC: 783643209930
✔ GTIN: 00783643209930
✔ Country of Origin: Mexico
✔ Weight: 3
✔ Panel Type: SB Switchboards, Sentron Panelboards
✔ Standards: IEC 60947-2, UL 489
