Square D JJL36250T Circuit Breaker | 600V 250A 3P 65kA@480V Feed-Thru Powerpact

Product Description:
The Square D JJL36250T is a Molded Case Circuit Breaker from the Powerpact family. It is a 3-pole breaker rated for 250 amps at 600 volts, with an AIC rating of 65kA at 480V. This model features a feed-thru connection and provides thermal magnetic protection for reliable circuit interruption.

Key Features:
✔ Part Number: JJL36250T
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: JJL
✔ Voltage: 600
✔ Amperage: 250
✔ Phase: 3
✔ Poles: 3
✔ AIC Rating: 65kA@480V
✔ Connection: Feed-Thru
✔ Functions: LI - Long-Time and Instantaneous
✔ Frame Size: J Frame
✔ Protection: Thermal Magnetic
✔ UPC: 785901854302
✔ GTIN: 00785901854302
✔ Country of Origin: United States
✔ Dimensions: Height 7.52 in (191 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
✔ Weight: 2.04
✔ Wire Size: AWG 3/0...350 kcmil aluminum/copper terminals
