Square D QOB390 Circuit Breaker | 240V 90A 3P 10kA@240V Bolt-on QOB Series

Product Description:
The Square D QOB390 is a Molded Case Circuit Breaker from the QOB Series. It is a 3-pole, 90 amp breaker rated for 240 volts with a 10kA interrupting capacity. This thermal magnetic circuit breaker uses a bolt-on connection for secure installation.

Key Features:
✔ Part Number: QOB390
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: QOB Series
✔ Type: QOB
✔ Voltage: 240
✔ Amperage: 90
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 10kA@240V
✔ Connection: Bolt-on
✔ Functions: LI - Long-Time and Instantaneous
✔ Terminal Connection: Lug
✔ Frame Size: 100A/QO
✔ MCM Size: Min. Wire Size 8 AWG Max. Wire Size 2 AWG
✔ Breaker Type: Standard
✔ Protection: Thermal Magnetic
✔ UPC: 785901019725
✔ GTIN: 00785901019725
✔ Country of Origin: Mexico
✔ Dimensions: 2.25 in x 3.5 in x 3.5 in
✔ Weight: 0.49
✔ Panel Type: Square D NQOD Panelboards
✔ Standards: CSA, UL Listed
✔ Certification: UL Listed
✔ Wire Size: 4 To 2/0 Awg (Aluminum/Copper)
