Square D QOU315VH Circuit Breaker | 240V 15A 3P 22kA@240V Bolt-On QOU Series
Square D QOU315VH Circuit Breaker | 240V 15A 3P 22kA@240V Bolt-On QOU Series
Price:
Sale
Sold out
Regular price
$184.86 USD
Regular price
$460.08 USD
Sale price
$184.86 USD
Unit price
per
Shipping calculated at checkout.
Stock:
Out of stock
Couldn't load pickup availability
Product Description:
The Square D QOU315VH is a 3-pole molded case circuit breaker with a 240V, 15A rating and 22kA@240V AIC rating. It features bolt-on connections and thermal magnetic protection for reliable performance. This breaker is part of the QOU Series family and is designed for industrial and commercial applications.
Key Features:
✔ Part Number: QOU315VH
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: QOU Series
✔ Type: QOU
✔ Voltage: 240
✔ Amperage: 15
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 22kA@240V
✔ Connection: Bolt-On
✔ Protection: Thermal Magnetic
✔ Dimensions: Height 4.05 in (102.87 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
✔ Certification: CSA - UL listed - IEC
✔ Wire Size: AWG 14...AWG 2 aluminum/copper
The Square D QOU315VH is a 3-pole molded case circuit breaker with a 240V, 15A rating and 22kA@240V AIC rating. It features bolt-on connections and thermal magnetic protection for reliable performance. This breaker is part of the QOU Series family and is designed for industrial and commercial applications.
Key Features:
✔ Part Number: QOU315VH
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: QOU Series
✔ Type: QOU
✔ Voltage: 240
✔ Amperage: 15
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 22kA@240V
✔ Connection: Bolt-On
✔ Protection: Thermal Magnetic
✔ Dimensions: Height 4.05 in (102.87 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
✔ Certification: CSA - UL listed - IEC
✔ Wire Size: AWG 14...AWG 2 aluminum/copper
