Square D HDF36070 Circuit Breaker | 600V 70A 3P 18kA@480V Bolt-On HDF Powerpact

Product Description:
The Square D HDF36070 is a Molded Case Circuit Breaker from the Powerpact family, designed for robust electrical protection.
It features a 3-pole, 70-amp rating at 600 volts with an 18kA@480V AIC rating and thermal magnetic protection.
This circuit breaker uses a bolt-on connection for secure installation and is built for reliable performance in industrial applications.

Key Features:
✔ Part Number: HDF36070
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Powerpact
✔ Type: HDF
✔ Voltage: 600
✔ Amperage: 70
✔ Phase: 3
✔ Poles: 3
✔ AIC rating: 18kA@480V
✔ Connection: Bolt-On
✔ Functions: LI - Long-Time and Instantaneous
✔ Frame Size: H Frame
✔ Protection: Thermal Magnetic
✔ UPC: 606486282406
✔ GTIN: 03606486282403
✔ Dimensions: Height 6.42 in (163 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
✔ Weight: 1.81
✔ Wire Size: AWG 14...AWG 3/0 aluminum/copper terminal
