Product Description:
The Square D HOM2200BB is a Molded Case Circuit Breaker from the Homeline family. It features a 2-pole design with a 240V, 200A rating and a 10kA@240V AIC rating. This breaker uses a plug-in connection and offers thermal magnetic protection for reliable performance.
Key Features:
✔ Part Number: HOM2200BB
✔ Manufacturer: Square D
✔ Category: Circuit Breaker
✔ Subcategory: Molded Case
✔ Family: Homeline
✔ Type: HOM
✔ Voltage: 240
✔ Amperage: 200
✔ Phase: 1
✔ Poles: 2
✔ AIC rating: 10kA@240V
✔ Connection: Plug-In
✔ Protection: Thermal Magnetic
✔ UPC: 785901876601
✔ GTIN: 00785901876601
✔ Country of Origin: United States
✔ Dimensions: Depth 10.53 in (267.46 mm) Width 16 in (406.40 mm) Height 52.5 in (1333.50 mm)
✔ Weight: 1.39 lb
✔ Panel Type: Homeline
✔ Certification: UL Listed
✔ Wire Size: 4 AWG to 300 KCMIL (Aluminum/Copper)
